Xilinx Virtex UltraScale Product Advantage

Xilinx Virtex® UltraScale™ devices provide the greatest performance and integration at 20nm, including serial I/O bandwidth and logic capacity. As the industry’s only high-end FPGA at the 20nm process node, this family is ideal for applications ranging from 400G networking to large scale ASIC prototyping and emulation.

Applications

4x100G Transponder

400G MAC to Interlaken Bridge

2x100G Muxponder

400G OTN Switching (POTS)

ASIC Prototyping & Emulation

Programmable System Integration

Up to 5.5M System Logic Cells at 20nm using 2nd generation 3D IC

Integrated 100G Ethernet MAC and 150G Interlaken cores

Increased System Performance

Up to two speed-grade improvement with high utilization

30G transceivers for chip-to-chip, chip-to-optics, 28G backplanes

16G backplane capable transceivers at half the power

2400Mb/s DDR4 for robust operation over varying PVT

BOM Cost Reduction

Up to 50% lower cost – half the cost per port for Nx100G systems

VCXO and fractional PLL integration reduces clocking component cost

2400Mb/s DDR4 in a mid-speed grade

Total Power Reduction

Up to 40% lower power vs. previous generation

Fine granular clock gating with ASIC-like clocking

Enhanced System Logic Cell packing reduces dynamic power

Accelerated Design Productivity

Footprint compatibility with Kintex® UltraScale devices for scalability

Seamless footprint migration from 20nm planar to 16nm FinFET

Co-optimized with Vivado® Design Suite for rapid design closure

Do you know more about Xilinx's product uses, technical documents, and solutions related to Virtex UltraScale? Then quickly get in touch with Xilinx Distributor - NHE!
